Model

SKA-100A-24V-12V

Input Voltage

DC18V-36V

Output Voltage

DC12V

Output Current

100A

Output Power

1200W

Ripple

<200mVp

Static Current

<70mA

Transfer Efficiency

≥95%

Working Temperature

-30~80℃

IP Rating

IP68

Size

220 x 127 x 63mm

Weight

2.5Kg

Packing

Neutral packing

Warranty

2 Years

Certification

CE & RoHS

Features

1.High-end integrated switching regulator module manufacturing.

2.Over voltage,over current,over temperature,short circuit protection.

3.Aluminum alloy shell, heat eliminable.

Application

Can be widely used for car,interphone,LED light,FM audio system,surveillance system,etc.
