48V 300W Pure Sine Wave Inverter

Products » Pure Sine Wave Inverter » 48V Inverter

Name :

48V 300W Pure Sine Wave Inverter

Color:

Blue

Size:

140 x 95 x 55mm

Material:

Aluminum alloy shell

[ Close ]

Description:

Specification

Model		SK-300W Series
Rated Power		300W
Continuous Power		300W
Peak Power		600W
Input Section	DC Input Voltage	12V	24V	48V
	DC Operating Voltage	11-15V	21-29V	40-60V
	DC Low Voltage Protection	9-11V	19-21V	39-40V
	DC Low Voltage Alarm	9-11V	19-21V	39-40V
	DC Over Voltage Protection	≥15V	≥29V	≥60V
	Fuse	20A*2	10A*2	5A*2
	Quiescent Current	≤0.5A	≤0.25A	≤0.13A
Output Section	Output Waveform	Pure Sine Wave
	Output Voltage	220V-240V
	Output Frequency	50Hz±1%
Transfer Efficiency		≥93%
Overload Protection		Yes
Short Circuit Protection		Yes
Cooling Type		By Cooling Fan
Operating Temperature		-10℃-50℃
Temperature Protection		≥70℃
Green LED Indicator		Green Light (Working)
Red LED Indicator		Red Light (Error Protection)
Size		140 x 95 x 55mm
Weight		0.85Kg

Features

1. High-end chip, high-performance CPU, improve the working reliability.
2. Over voltage, low voltage, over temperature, over load, short circuit, reverse connect protection.
3. Sound alarm, with cooling fan.
4. Soft-start function, increase loading capacity.
5. Aluminum alloy shell, heat eliminable.

Application

Can be widely used for solar energy system, wind energy system, fridge, refrigerator, air-condition, water pump, motor, car, LED light, camera, fan, hair dryer, electric light, electric kettle, TV set, CD player, mobile phone, laptop, portable device, etc.
