Model

SK-60A-24V-12V

Input Voltage

DC13V-40V

Output Voltage

DC12V±10%

Output Current

60A

Transfer Efficiency

≥95%

Rated Power

720W

Max Power

790W

Working Temperature

-20~80℃

Temperature Protection

80℃±10%

Static current

<60mA

Size

275 x 165 x 67mm

Weight

1.45Kg

Packing

Neutral color box packing

Warranty

2 Years

Certification

CE

Features

1.High-end integrated switching regulator module manufacturing.

2.Overvoltage,overcurrent,over temperature, short circuit protection.

3.Aluminum alloy shell, heat eliminable.

Application

Can be widely used for car,bus,truck,interphone,FM audio system,surveillance system,etc.
